過濾器的選擇準則
For optimum efficiency and throughput, it is recommended
優化效率和吞吐量，it is recommended
that you select a filtration scheme based on
你選擇了基于過濾方案
flow and differential pressure requirements.
流量和微分壓力的要求。
To select your filter simply:
簡：選擇你的filter to
A. Select desired level of filtration (refer to Table 8 for
答：選擇要過濾的表（refer to level of 8 for
reference).
參考）。
B. Select filter cartridge style and grade by referring to
B選擇過濾器墨盒風格和品位by referring to
Tables 1, 2, 3, 4 and 5.
表1、2、3、4和5。
C. Confirm that the Profile II filter medium selected is
訴confirm that the Profile II過濾介質selected is
compatible with the fluid and the operating temperature.
符合流體和操作溫度。
See Table 9.
見表9。
D. Determine the required number of 10 inch filter
D determine the required number of 10英寸過濾器
modules by dividing the system flow rate by the typical
模塊的劃分系統流速by the典型
flow rate per 10 inch module given in Table 6.
流動率每10英寸模塊給出表6。
Calculate the clean pressure drop to verify that it is
計算清潔壓力to verify that it is
acceptable.
可接受的。
E. Refer to Table 7 for ordering information on housings.
Refer to表。7 for訂購信息器外殼。
Determine stacking array (number of cartridges
確定疊加陣列（number of cartridges
and length) of RF or AB series filter element(s) for
和長度）的金元素AB系列射頻濾波器（S）。
selected housing.
選擇住房。
F. Refer to Table 2 to complete ordering information
Refer to表F 2 to complete訂購信息
for desired filter element(s).
for需要過濾元素（S）。
For example: You require a filter cartridge for 40 μm
例如：你需要的過濾器墨盒for 40μ
removal in an RF style. Your flow rate is 100 gpm.
Removal in an RF的風格。你的流動率是100加侖。
Therefore, from Table 6 you require approximately 6-
因此，你需要從表6約6
10, 10" filter modules (100 gpm divided by 15 gpm
10“過濾模塊（100加侖divided by 15加侖
per 10" cartridge). From Table 7, you require a P04
每10”指南）。表7，你需要有P04
housing which can accept four 20" or 30" filter cartridges.
住房，可以接受“金爐20 30 cartridges”過濾器。
Four 20" filter cartridges (8, 10" filter modules)
“cartridges爐20濾波器（8，10”濾波器模塊）
meet your requirements.
滿足你的要求。
The part number for your filter cartridge would be:
the part number的過濾器墨盒將：
R2F400
r2f400
The part number stands for:
the part number stands for：
R: style-retrofit
R：風格的改進
2: 20" length
2：20”長度。
F400: 40 μm absolute rated, polypropylene Profile II
f400：40μm絕對評，聚丙烯Profile I
